Formax ReadyWire2B Office Manual Punch & Wire Binding System 2:1 Pitch
Details
Details
Formax ReadyWire 2B Manual Punch & Binding System - 2:1 Pitch
The Formax ReadyWire 2B is a compact manual punching and binding system designed for offices and organizations with low binding volumes. Its 2:1 pitch configuration provides greater binding versatility, accommodating double-loop wire diameters from 1/4" to 1-1/4" and finished booklets up to 280 sheets.
An ergonomic two-lever design separates punching and binding operations for simple, comfortable use. The low-force punching lever can punch up to 20 sheets at a time, while the integrated wire comb holder helps keep pages properly positioned before binding. A built-in wire diameter guide and quick-adjust sliding binding control make it easy to select and set the appropriate wire size for each project.
The ReadyWire 2B produces professional wire-bound documents that open a full 360 degrees and lay flat for easier reading, writing, copying, and scanning. Double-loop wire securely holds pages in place while providing a clean, professional finished appearance.
Key Features
- 2:1 pitch punching and binding system
- Manual punching and binding operation
- Compact, rugged metal construction
- Ergonomic two-lever system
- Low-force punching of up to 20 sheets at a time
- Binding capacity up to 280 sheets
- Supports 1/4" to 1-1/4" diameter double-loop wire
- Integrated wire comb holding device for easier paper positioning
- Integrated wire diameter measurement guide
- Quick sliding adjustment for binding diameter
- Fixed punching margin depth
- Adjustable paper stop
- Easy-empty sliding waste tray
- Smooth, quiet operation
- Finished documents open 360 degrees and lay flat
Specifications
| Model | ReadyWire 2B |
|---|---|
| Pitch | 2:1 |
| Punching / Binding | Manual |
| Punching Capacity | Up to 12,000 sheets per hour |
| Sheets Per Punch | Up to 20 sheets |
| Punching Width | 0.39" to 11.8" (10 to 300 mm) |
| Maximum Punching Thickness | Up to 0.08" (2 mm) |
| Punch Hole | Rectangle, 5.5 x 3.5 mm |
| Binding Speed | Up to 200 books per hour |
| Maximum Binding Capacity | Up to 280 sheets |
| Wire Diameter | 1/4" to 1-1/4" |
| Dimensions | 23" W x 13" D x 17.5" H (584 x 330 x 445 mm) |
| Weight | 34 lb (15.4 kg) |
Easy Setup and Adjustment
The ReadyWire 2B includes an onboard wire diameter guide with clear graphics to help operators select the appropriate wire gauge for each project. Binding dimensions can be changed quickly using the sliding adjustment, helping streamline setup when moving between different booklet thicknesses.
Versatile 2:1 Wire Binding
The 2:1 pitch format is designed for applications requiring a wider range of binding capacities. The ReadyWire 2B accepts wire diameters from 1/4" through 1-1/4", allowing it to produce everything from thin presentations to larger documents containing up to 280 sheets.
For convenient loading, the integrated wire comb holder keeps the binding wire in position while punched sheets are placed onto the loops. Once bound, documents can rotate a full 360 degrees and lay flat, making them well suited for manuals, reports, presentations, reference materials, and other frequently handled documents.
