GBC Part Number 704090313 RUBBER KEY S/W U-65 637400077
Details
Details
This part is often the fix for the Ultima 65 lamintor (or 65-1) when the laminator runs backwards or pressing "Stop" doesn't stop or when it runs in reverse when "Run" is pressed:
With the original Ultima 65 or 65-1, the issue is likely the rubber keypad that sits on top of the control PCB. When it gets worn down, it can create issues with the Reverse, Run and Stop buttons.
I would start with replacing part number "704090313 - RUBBER KEY S/W U-65 637400077". 99% of the time replacing this part resolves this issue. We have technicians that can replace this for you if you don't have your own tech.
Question:
When we push the button second from the bottom (Run?) over time the laminator has become more and more non-cooperative.
Eventually the button had a "sweet spot" that had to be carefully pushed to get the laminator to operate. Now, there is either no reaction to pushing the button, or the wheels on the machine begin to turn backward.
We have an identical machine in another building. When we swapped this part with the one that we know works, the machine worked perfectly.
Technician Answer:
If the model is an Ultima 65-1, most likely what you'll need is the rubber keypad (membrane) that sits between the buttons and the control PCB.
This is the most commonly replaced part on the 65-1 model, and 99% of the time resolves issues with unresponsive controls. I would recommend Part Number 704090313.
The reason for the machine working when you swapped the control PCB from another machine is likely because you either a) kept the rubber keypads on their respective boards, so technically the pad on the old machine was being replaced, or b) as these keypads wear down, sometimes a slight realignment can make them work again until they slip back into its original position, then it'll stop working again.
If after replacing the rubber keypad you still have issues, then I would look at replacing the control PCB itself.
Get a NEW GBC Part #704090313 (RUBBER KEY S/W U-65 637400077) shipped to you!
This part is guaranteed to work with your GBC machine. Parts are shipped directly to your door for your convenience. If you need rush delivery, please call us at 1-866-455-9900. If you have other questions regarding parts for your machine, click here to contact us.
To check stock or ask questions about your machine or parts, call 1-866-455-9900. View our Parts Warranty and Return Policy Here.
If you need to find a part for your machine, check out our Machines Parts Lists to find the one you need.
To order a 704090313 RUBBER KEY S/W U-65 637400077 by phone, call 1-866-455-9900. Thank you for choosing Skyline!
Parts have a 30 day return policy. *Electric parts are non-returnable.
